AC 120-240V power supply
Built-in transformer
Electronic limit switch
Built-in receiver
3rd intermediate limit position
Features:
• Compact design
• 25mm diameter
• 3 adjustable speeds
• Motor can fit 38mm tube
| Rated Torque (Nm) |
2 |
| Speed (rpm) |
25/30/35 |
| Lifting Capacity (m) |
3x3 |
| Nominal Consumption (W) |
13.6 |
| Nominal Voltage (V) |
100-240 |
| Nominal Current (A) |
0.24 |
| Running Time (mins) |
4 |
| Protection Index (IP) |
20 |
| Total Length (mm) |
532 |
| Maximum Turns (turn) |
Infinity |
| Net Weight (Kg) |
0.5 |
| INCLUDED C&D |
A2310 |
